Chrome sand AFS35-40 AFS40-45 AFS55-60 from China

Chrome sand AFS35-40 AFS40-45 AFS55-60 from China is an superior molding sand for Iron and steel casting. It gains low thermal expansion rate, high thermal resistanc and good thermal conductivity. The chrome sand is produced in China after import raw chrome ore from South Africa. We make dry, magnetic removal, sieving process in our plants to make sure low moisture, 46% Chromium content and lowe silica in the sand.

$550.00 – $600.00 / MT

Add to quote

Chrome sand AFS35-40 AFS40-45 AFS55-60 from China

Product Name: Chrome sand

Other name: Chromite sand, chromite sand for casting, chromite sand for foundry, foundry grade chromite sand, chrome ore sand, 크롬모래,크롬샌드,크롬모래 내화 물질,크롬샌드 주조모래,クロマイトサンド, ромовая руда,Хромитовый песок,Хромитовый песок AFS РосКварц,Хромит песок, Хромит,sable de chromite,chromitsand,ChromerzsandSabbia di Cromite,arena de cromita,Arena Cromita,Fundición cromita,Areia de Cromita,Areia cromada,Piasek chromitowy,

Chrome sand AFS35-40 AFS40-45 AFS55-60 from China is an superior molding sand for Iron and steel casting. It gains low thermal expansion rate, high thermal resistanc and good thermal conductivity. The chrome sand is produced in China after import raw chrome ore from South Africa. We make dry, magnetic removal, sieving process in our plants to make sure low moisture, 46% Chromium content and lowe silica in the sand.

Moulding chromite sand for sale Characteristics:
  1. High melting point, high sintering temperature
  2. Excellent thermal stability
  3. High density, high density –
  4. Medium Mohs hardness 5.5
  5. Strong thermal conductivity
  6. Low coefficient of thermal expansion



Technical Index of Moulding chromite sand for sale:
  1. Chemicals
ContentGuarantee ValueTypical Value
Cr2O3 ≥ 46%46.70
SiO2≤ 1.0%0.61
FeO≤ 26.5%26.2
Cr:Fe≥1.5:11.55
MgO≤ 10%9.8
CaO≤ 0.3%0.3
Al2O3≤ 15.5%15.4
P≤30 ppm28 ppm
S≤30 ppm27 ppm



  1. Physical index:
Mohs Hardness5.5-6
Melting Point2180 ℃
Sintering Point＞1800℃
Specific Gravity4.0-4.8 g/cm3
Bulk Density (LPD)2.5-3 g/cm3
ColorBlack
PH Value7-9
Thermal conductivity0.63 W/M·K
Thermal Expansion Rate（1000℃）0.6%
Acid Demand Value (ADV)PH3:≤ 3ML

PH4: ≤ 2ML

PH5: ≤ 2ML

Turbidity(NTU)≤ 200
Soil content≤0.1%
Moisture≤0.1%





Available specification of Moulding chromite sand for sale:



AFS FinenessMeshGrain Size
AFS 25-3020-40#0.45-0.85mm
AFS 30-3520-50#0.3-0.85mm
AFS 30-4020-60#0.25-0.85mm
AFS 35-4030-70#0.2-0.6mm
AFS 40-4540-70#0.2-0.4mm
AFS 45-50/AFS45-55/AFS50-5550-100#0.15-0.3mm
AFS 60-6570-140#0.1-0.2mm
/200#-00-75um
/325#-00-45um





Applications of Moulding chromite sand for sale:
  1. Large scale thick walled casting: Chromite sand combined with sand casting, furan resin self hardening sand, water glass self hardening sand and other processes are used for large volume and weight cast iron and steel castings. It can cool the castings in a predetermined order, which is conducive to improving the internal tightness of the castings and enhancing their strength. In addition, for the process of using silica sand, chromite ore sand can be used as surface sand instead of silica sand in key areas where porosity and veins are prone to occur, which can effectively prevent casting defects such as cracks and porosity.
  2. Lost foam casting. In lost foam casting, using chrome ore sand can prevent defects such as sand inclusion and sticking caused by quartz sand casting. Used for manufacturing castings such as valves and impellers made of high chromium cast steel and high manganese steel materials.
  3. Shell casting: Chromite sand can be used as a core sand material for complex components in shell casting, making sand cores. Used for producing high-precision, smooth surface 304316 stainless steel castings and carbon steel precision castings. It can effectively prevent the problem of sand sticking in the inner cavity of castings.
  4. Sand casting: Chromite sand can also be used for sand casting, such as sand casting, water glass self hardening sand casting, etc., to produce various large, medium, and small parts, such as pump bodies, pipelines, valves, etc.

Production of Moulding chromite sand:



Package of Moulding chromite sand for sale:
