Foundry chromite sand AFS 45/55 key technical index

Foundry chromite sand AFS 45-55 key technical index

Foundry-grade chromite sand AFS 45-55 – the work-horse for heavy-section steel and manganese-steel castings – is bought on a very short list of numbers.
The “key technical index” that meet GOST 23409.24-78  and SFSA 16 T-67 standard given below. If any item drifts outside these bands the sand is either rejected or priced down.

Index Requirement
SiO₂ ≤ 1.0 %
Cr₂O₃ ≥ 46 %
FeO + Fe₂O₃ (total Fe as FeO) 26 – 30 %
Al₂O₃ ≤ 12 %
MgO ≤ 8 %
CaO ≤ 0.5 %
P ≤ 0.003 %
S ≤ 0.002 %
Cr/Fe ≥ 1.55:1
Loss on ignition (1 000 °C) ≤ 0.2 %
Acid demand value (ADV) ≤ 5 ml
PH 7-9
Moisture ≤ 0.1 %
Bulk density 2.6 – 2.8 g cm⁻³
Specific gravity 4.4 – 4.6 g cm⁻³
Thermal linear expansion (20 – 1 000 °C) ≤ 0.4 %
Thermal conductivity 0.63 W/M·K
Melting point ≥ 1 800 °C
Grain shape sub-angular to angular
Colour glossy black
Magnetic particles ≤ 0.1 %
NTU ≤ 300
Grain Fineness number (GFN) AFS 45-55(AFS45/55)
Average grain size 0.26-0.32mm



Notes
1. The Cr₂O₃ ≥ 46 % gate is the single most important discriminator; below 45 % the refractoriness and chilling power fall off quickly.
2. SiO₂ > 1 % is rejected outright because free silica accelerates burn-on and fayalitic penetration in manganese-steel casts.
3. ADV ≤ 3 ml guarantees that the sand will not rob acid from phenolic-urethane or furan binders, keeping strip times and strengths on target.
4. AFS 45/55 corresponds to a weight median diameter of ≈ 260–320 µm – coarse enough for high permeability in 100 kg–50 t moulds, fine enough to give a 3–4 µm Ra surface on the casting.
